基于燃烧前CO2捕集与封存的IGCC全生命周期碳排放及环境评价

doi:10.11949/0438-1157.20250628

摘要/Abstract

摘要：

为评估整体煤气化联合循环（IGCC）电厂耦合燃烧前碳捕集与封存（CCS）的碳排放及环境影响，采用全生命周期评价（LCA）方法，利用SimaPro软件建模，研究了未实施/实施碳捕集IGCC电厂的全球变暖潜值（GWP）、陆地酸化潜值（TAP）、致癌人体毒性潜值（HTPc）、非致癌人体毒性潜值（HTPnc）、陆地生态毒性潜值（TETP）、淡水生态毒性潜值（FETP）及淡水富营养化潜值（FEP）七种环境影响类型及其主要贡献源，并对未实施/实施碳捕集IGCC电厂的各类环境影响程度进行比较。结果表明，相比于未实施碳捕集，碳捕集后电厂的烟气碳排放降低88%，煤炭与化学品供应与辅机用电所造成的GWP分别上升了18%和20%，CCS过程的GWP为39.02 kg CO₂-eq，电厂生命周期总GWP为257 kg CO₂-eq，降低了72%。除GWP显著下降外，捕集电厂的TAP、HTPc、HTPnc、TETP、FETP和FEP环境影响潜值均上升至未捕集电厂的119%~170%。煤炭和化学品供应的增加是HTPc上升的主要因素，而CCS单元是除HTPc外其他环境影响潜值上升的主要贡献源，占捕集电厂各类环境影响潜值的15%~34%。

关键词: 煤燃烧, 二氧化碳捕集, 温室气体, 可持续性, 模型, 模拟, 环境

Abstract:

In this work, a life cycle assessment (LCA) methodology was applied to access the carbon emission and potential environment impacts of the integrated gasification combined cycle (IGCC) power plant with pre-combustion carbon capture. The assessment was carried out by SimaPro software modeling. The global warming potential (GWP), terrestrial acidification potential (TAP), carcinogenic human toxicity potential (HTPc), non-carcinogenic human toxicity potential (HTPnc), terrestrial ecotoxicity potential (TETP), freshwater ecotoxicity potential (FETP), freshwater eutrophication potential (FEP) and the related contributors were investigated and compared for the IGCC power plants with/without carbon capture and storage (CCS). The results showed that compared to the power plant without carbon capture, flue gas carbon emissions decreased by 88% after carbon capture, while the GWP caused by coal and chemical supply and auxiliary power consumption increased by 18% and 20%, respectively. The GWP of the CCS process was 39.02 kg CO₂-eq, and the total life-cycle GWP of the power plant was 257 kg CO₂-eq, with a reduction of 72%. Besides the sharp drop in GWP, the potential environmental impact of the plant, including TAP, HTPc, HTPnc, TETP, FETP and FEP, increased to 119%—170% compared to the benchmark plant without CCS. The increase in coal and chemical supply was the primary contributor to the rise in HTPc. The CCS unit was the primary contributor to the increase of potential environmental impact except HTPc, and the CCS unit accounted for 15%—34% of the potential environmental impact of the plant.

Key words: coal combustion, CO₂ capture, greenhouse gas, sustainability, model, simulation, environment

中图分类号:

TQ 548

陈时熠, 曹欣欣, 陈姝屹, 李绩新, 向文国. 基于燃烧前CO₂捕集与封存的IGCC全生命周期碳排放及环境评价[J]. 化工学报, 2025, 76(12): 6573-6586.

Shiyi CHEN, Xinxin CAO, Shuyi CHEN, Jixin LI, Wenguo XIANG. Life cycle carbon emission and environment assessment of pre-combustion IGCC power plant[J]. CIESC Journal, 2025, 76(12): 6573-6586.

图/表 18

参考文献 34

[1]	IEA. CO₂ Emissions in 2023[EB/OL]. Paris: International Energy Agency, 2024[2025-05-05]. .
[2]	张金良, 贾凡. 中国火电行业多模型碳达峰情景预测[J]. 电力建设, 2022, 43(5): 8-28.
	Zhang J L, Jia F. Multi-model carbon peak scenario prediction for thermal power industry in China[J]. Electric Power Construction, 2022, 43(5): 18-28.
[3]	单思珂, 刘含笑, 刘美玲, 等. 我国火电行业碳足迹评估综述[J]. 发电技术, 2024, 45(4): 575-589.
	Shan S K, Liu H X, Liu M L, et al. Review of carbon footprint for thermal power industry in China[J]. Power Generation Technology, 2024, 45(4): 575-589.
[4]	国家能源局. 2023年全国电力工业统计数据[R]. 中国: 国家能源局, 2024.
	National Energy Administration. Statistical data of the national electric power industry in 2023[R]. China: NEA, 2024.
[5]	中国电力企业联合会. 中国电力行业年度发展报告2024[R]. 中国: 中国电力企业联合会, 2024.
	China Electricity Council. Annual development report of China's electric power industry 2024[R]. China: CEC, 2024.
[6]	周宏春. 新型能源体系破解能源保供与降碳双重压力研究与探讨[J]. 中国煤炭, 2023, 49(5): 1-10.
	Zhou H C. Research and discussion on breaking the dual pressure of energy supply guarantee and carbon reduction by the new energy system[J]. China Coal, 2023, 49(5): 1-10.
[7]	潘家华, 陈梦玫, 刘保留. 净零碳转型的主要路径及其优化集成[J]. 中国人口·资源与环境, 2023, 33 (11): 1-12.
	Pan J H, Chen M M, Liu B L. Main paths of the net-zero carbon transition and optimal integration[J]. China Population, Resources and Environment, 2023, 33 (11): 1-12.
[8]	舒印彪, 赵勇, 赵良, 等. “双碳”目标下我国能源电力低碳转型路径[J]. 中国电机工程学报, 2023, 43(5): 1663-1672.
	Shu Y B, Zhao Y, Zhao L, et al. Study on low carbon energy transition path toward carbon peak and carbon neutrality[J]. Proceedings of the CSEE, 2023, 43(5): 1663-1672.
[9]	张全斌, 周琼芳. 基于“双碳”目标的中国火力发电技术发展路径研究[J]. 发电技术, 2023, 44(2): 143-154.
	Zhang Q B, Zhou Q F. Research on the development path of China's thermal power generation technology based on the goal of “carbon peak and carbon neutralization”[J]. Power Generation Technology, 2023, 44(2): 143-154.
[10]	Xu G, Yang Y P, Ding J, et al. Analysis and optimization of CO₂ capture in an existing coal-fired power plant in China[J]. Energy, 2013, 58: 117-127.
[11]	Zhao B, Liu F Z, Cui Z, et al. Enhancing the energetic efficiency of MDEA/PZ-based CO₂ capture technology for a 650 MW power plant: process improvement[J]. Applied Energy, 2017, 185: 362-375.
[12]	樊静丽, 李佳, 晏水平, 等. 我国生物质能-碳捕集与封存技术应用潜力分析[J]. 热力发电, 2021, 50(1): 7-17.
	Fan J L, Li J, Yan S P, et al. Application potential analysis for bioenergy carbon capture and storage technology in China[J]. Thermal Power Generation, 2021, 50(1): 7-17.
[13]	高明楷, 杨普, 吴海滨, 等. 碳减排情景下燃煤电厂烟气脱硫技术优化及评价方法[J]. 洁净煤技术, 2022, 28(7): 177-188.
	Gao M K, Yang P, Wu H B, et al. Development of optimization and evaluation methods of flue gas desulfurization technology for coal-fired power plants under carbon emission reduction scenarios[J]. Clean Coal Technology, 2022, 28(7): 177-188.
[14]	Rubin E S, Kalagnanam J R, Frey H C, et al. Integrated environmental control modeling of coal-fired power systems[J]. Journal of the Air & Waste Management Association, 1997, 47(11): 1180-1188.
[15]	Gerbelová H, Versteeg P, Ioakimidis C S, et al. The effect of retrofitting Portuguese fossil fuel power plants with CCS[J]. Applied Energy, 2013, 101: 280-287.
[16]	齐国杰, 王淑娟, 余景文, 等. 氨水溶液联合脱除燃煤烟气中CO₂和SO₂的模拟和经济性分析[J]. 中国电机工程学报, 2013, 33(17): 16-23, 6.
	Qi G J, Wang S J, Yu J W, et al. Modeling and economic analysis on combined capture of CO₂ and SO₂ in flue gas using aqueous ammonia[J]. Proceedings of the CSEE, 2013, 33(17): 16-23, 6.
[17]	岳朴杰, 孟磊, 王长清, 等. 300 MW燃煤电厂生命周期排放气态有机污染物环境影响[J]. 洁净煤技术, 2022, 28(5): 173-181.
	Yue P J, Meng L, Wang C Q, et al. Environmental impact of gaseous organic pollutants emitted from 300 MW coal-fired power plant during lifecycle[J]. Clean Coal Technology, 2022, 28(5): 173-181.
[18]	张晓玉. 燃煤电厂烟气超净排放系统生命周期评价研究[D]. 济南: 山东大学, 2018.
	Zhang X Y. Life cycle assessment research of ultra-clean flue gas emission system in coal-fired power plant[D]. Jinan: Shangdong University, 2018.
[19]	刘安源, 刘丝雨, 马玉峰. 3种燃煤供暖锅炉环境影响的生命周期评价[J]. 洁净煤技术, 2016, 22(1): 66-70.
	Liu A Y, Liu S Y, Ma Y F. Comparison of environmental impact for three different coal-fired boilers using life cycle assessment method[J]. Clean Coal Technology, 2016, 22(1): 66-70.
[20]	樊强, 许世森, 刘沅, 等. 基于IGCC的燃烧前CO₂捕集技术应用与示范[J]. 中国电力, 2017, 50(5): 163-167, 184.
	Fan Q, Xu S S, Liu Y, et al. Application and demonstration of IGCC-Based pre-combustion CO₂ capture technology[J]. Electric Power, 2017, 50(5): 163-167, 184.
[21]	朱宝田. IGCC电站设计集成与动态特性研究[J]. 热力发电, 2009, 38(2): 1-4.
	Zhu B T. Research on design integration and dynamic characteristics of integrated gasification combined cycle (IGCC) power plants[J]. Thermal Power Generation, 2009, 38(2): 1-4.
[22]	张浩儒, 张国强, 余建豪, 等. 煤气化特性优化及低碳联合循环发电系统集成研究[J]. 热力发电, 2024, 53(7): 91-100.
	Zhang H R, Zhang G Q, Yu J H, et al. Study on optimization of coal gasification characteristics and integration of its low carbon combined power generation system[J]. Thermal Power Generation, 2024, 53(7): 91-100.
[23]	National Energy Technology Laboratory. Cost and performance baseline for fossil energy plants. Volume 1: Bituminous coal and natural gas to electricity[R]. America: NETL, 2022.
[24]	Zhang Y, Wang N L. Intelligent energy-saving decision making and delicacy management for power enterprises[J]. Applied Mechanics and Materials, 2014, 631/632: 1282-1286.
[25]	Tao M, Cheng W Q, Nie K M, et al. Life cycle assessment of underground coal mining in China[J]. Science of the Total Environment, 2022, 805: 150231.
[26]	Petrescu L, Cormos C C. Environmental assessment of IGCC power plants with pre-combustion CO₂ capture by chemical & calcium looping methods[J]. Journal of Cleaner Production, 2017, 158: 233-244.
[27]	Porter R T J, Fairweather M, Kolster C, et al. Cost and performance of some carbon capture technology options for producing different quality CO₂ product streams[J]. International Journal of Greenhouse Gas Control, 2017, 57: 185-195.
[28]	Xia C Y, Ye B, Jiang J J, et al. Prospect of near-zero-emission IGCC power plants to decarbonize coal-fired power generation in China: implications from the GreenGen project[J]. Journal of Cleaner Production, 2020, 271: 122615.
[29]	Liang X Y, Wang Z H, Zhou Z J, et al. Up-to-date life cycle assessment and comparison study of clean coal power generation technologies in China[J]. Journal of Cleaner Production, 2013, 39: 24-31.
[30]	Ghoreishi S M, Hedayati A, Ansari K. Experimental investigation and optimization of supercritical carbon dioxide extraction of toxic heavy metals from solid waste using different modifiers and chelating agents[J]. The Journal of Supercritical Fluids, 2016, 117: 131-137.
[31]	葛众, 熊肖, 李健, 等. 基于LCA的有机朗肯循环技术环保性能研究综述[J]. 工程热物理学报, 2024, 45(8): 2262-2276.
	Ge Z, Xiong X, Li J, et al. A review on full life cycle research of organic Rankine cycle technology[J]. Journal of Engineering Thermophysics, 2024, 45(8): 2262-2276.
[32]	董志坚, 叶学民, 宋睿哲, 等. 集成ORC的太阳能辅助燃煤碳捕集发电系统全生命周期分析[J]. 动力工程学报, 2022, 42(7): 647-656.
	Dong Z J, Ye X M, Song R Z, et al. Life cycle assessment of coal-fired solar-assisted carbon capture power generation system integrated with ORC[J]. Journal of Chinese Society of Power Engineering, 2022, 42(7): 647-656.
[33]	Zhao H J, Dong J L, Chen S J, et al. Metal-organic frameworks and their composites for carbon dioxide capture: recent advances and challenges[J]. Fuel, 2024, 378: 132973.
[34]	宋鑫, 贝耀平, 袁丙青, 等. 水上光伏电站对淮南采煤沉陷积水区水生态环境的影响[J]. 水资源保护, 2022, 38(5): 204-211.
	Song X, Bei Y P, Yuan B Q, et al. Influence of floating photovoltaic power plants on water ecological environment in coal mining subsidence water area of Huainan City[J]. Water Resources Protection, 2022, 38(5): 204-211.

输入条件	参数
气化炉	Shell
氧化剂	95%（体积）O₂、4.2%（体积）N₂、0.8%（体积）Ar
煤种	伊利诺伊州6号烟煤
气化压力	4.2 MPa
气化温度	1427℃
氧煤比	0.72
H₂S分离技术	Sulfinol-M
脱硫率	99.5%
压缩机压比	15.7
HRSG排烟温度	132℃
蒸汽循环条件	12.4 MPa/561℃/561℃
燃气轮机型号	GE 7FA
燃气轮机数量	2

输入条件	参数
气化炉	Shell
氧化剂	95%（体积）O₂、4.2%（体积）N₂、0.8%（体积）Ar
煤种	伊利诺伊州6号烟煤
气化压力	4.2 MPa
气化温度	1427℃
氧煤比	0.72
H₂S分离技术	Sulfinol-M
脱硫率	99.5%
压缩机压比	15.7
HRSG排烟温度	132℃
蒸汽循环条件	12.4 MPa/561℃/561℃
燃气轮机型号	GE 7FA
燃气轮机数量	2

机组参数	IECM	报告机组	误差/%
燃气轮机输出/MW	457.5	464	1.40
汽轮机输出/MW	300.1	301	0.30
总发电量/MW	757.7	765	0.95
净发电量/MW	666.9	640	4.2
机组净热耗/(kJ/kWh)	8378	8377	0.01
发电效率/%	42.97	43	0.07
空分机组耗电/MW	62.4	61.36	1.7
煤耗量/(t/h)	205.8	197.5	4.2
合成气体积组分	1.04%Ar，57.22%CO， 1.75%CO₂，30.09%H₂，5.85%N₂，3.13%H₂O，0.81%H₂S等	0.91%Ar，57.53%CO，1.88%CO₂，29.37%H₂，5.75%N₂，3.23%H₂O，0.81%H₂S等	—
烟气体积成分	74.09%N₂，12.11%O₂，4.9%H₂O，7.81%CO₂等	74.95%N₂，11.22%O₂，5.31%H₂O，7.61%CO₂等	—

机组参数	IECM	报告机组	误差/%
燃气轮机输出/MW	457.5	464	1.40
汽轮机输出/MW	300.1	301	0.30
总发电量/MW	757.7	765	0.95
净发电量/MW	666.9	640	4.2
机组净热耗/(kJ/kWh)	8378	8377	0.01
发电效率/%	42.97	43	0.07
空分机组耗电/MW	62.4	61.36	1.7
煤耗量/(t/h)	205.8	197.5	4.2
合成气体积组分	1.04%Ar，57.22%CO， 1.75%CO₂，30.09%H₂，5.85%N₂，3.13%H₂O，0.81%H₂S等	0.91%Ar，57.53%CO，1.88%CO₂，29.37%H₂，5.75%N₂，3.23%H₂O，0.81%H₂S等	—
烟气体积成分	74.09%N₂，12.11%O₂，4.9%H₂O，7.81%CO₂等	74.95%N₂，11.22%O₂，5.31%H₂O，7.61%CO₂等	—

单元	机组参数	案例一	案例二
空分单元	氧气流量/(kg/MWh)	281.7	332.7
	氧气纯度/%（体积）	95	95
	氧气出口压力/MPa	4	4
气化炉	类型	GE（水煤浆激冷）	GE（水煤浆激冷）
	运行温度/℃	1343	1343
	运行压力/MPa	4.24	4.24
	水煤浆进料比例/(mol H₂O/mol C)	0.45	0.45
	氧化剂进料比例/(mol O₂/mol C)	0.43	0.43
酸性气体脱除	溶剂	Selexol	Selexol
	COS转化率/%	98.5	98.5
	H₂S去除率/%	98	98
	COS去除率/%	33	33
	CO₂去除率/%	15	15
水汽变换	CO转化率/%	—	95
水汽变换	COS转化率/%	—	98.5
碳捕集	溶剂	—	Selexol
	CO₂捕集率/%	—	95
	H₂S去除率/%	—	94
管道运输	距离/km	—	100
	入口压力/MPa	—	13.79
	出口压力/MPa	—	11.94
发电单元	燃气轮机功率/MW	235	228
	汽轮机功率/MW	107	108
	总功率/MW	342	336
	净功率/MW	289.2	262.8

基于燃烧前CO₂捕集与封存的IGCC全生命周期碳排放及环境评价

Life cycle carbon emission and environment assessment of pre-combustion IGCC power plant

RichHTML

PDF (PC)

可视化

摘要/Abstract

引用本文

使用本文

图/表 18

参考文献 34

相关文章 15

编辑推荐

Metrics

本文评价

辅机	功率/MW
辅机	案例一	案例二
ASU	37.92	39.98
气化炉	3.87	4.15
合成气净化	4.25	5.06
其他	6.84	6.71
水汽变换	0	-12.98
CO₂捕集	0	29.81

烟气成分	案例一	案例二
N₂	64.89%（体积）	66.69%（体积）
O₂	9.98%（体积）	10.19%（体积）
H₂O	15.01%（体积）	21.93%（体积）
CO₂	9.95%（体积）	1.01%（体积）
Ar	0.15%（体积）	0.16%（体积）
HCl	3350×10^-6	3470×10^-6
SO₂	708×10^-6	86.3×10^-6
NO	855×10^-6	855×10^-6
NO₂	44.9×10^-6	44.9×10^-6

参数	数值
煤炭开采
电力/(MJ/t)	91.04
水/(kg/t)	1672
钢材/(kg/t)	2.59
木材/(kg/t)	2.78
汽油/(kg/t)	0.37
柴油/(kg/t)	0.26
煤炭洗选
电力/(MJ/t)	15.66
水/(kg/t)	2730
锰/(kg/t)	2.72
煤炭运输
运输方式	铁路 + 公路
运输距离/km	100

消耗	消耗数值	排放	排放数值
混凝土	1.25 kg/MWh	氨	1.55×10^-6 kg/MWh
铝板	5.19×1010^-3 kg/MWh	二氧化碳	7.71×10^-1 kg/MWh
钢管	2.17×10^-2 kg/MWh	一氧化碳	2.97×10^-3 kg/MWh
钢板	1.58×10^-1 kg/MWh	灰尘	8.32×10^-4 kg/MWh
铁	2.94×10^-3 kg/MWh	铅	3.31×10^-8 kg/MWh
电力	6.69×10^-3 MJ/MWh	汞	5.83×10^-4 kg/MWh
热能	1.71×10^-3 MJ/MWh	甲烷	1.61×10^-3 kg/MWh
		氮氧化物	1.76×10^-5 kg/MWh
		二氧化硫	2.76×10^-3 kg/MWh
		六氟化硫	9.06×10^-12 kg/MWh
		挥发性有机化合物	6.08×10^-5 kg/MWh

消耗	消耗数值	排放	排放数值
混凝土	7.96×10^-3 kg/MWh	二氧化碳	6.74×10^-1 kg/MWh
铝板	2.06×10^-5 kg/MWh	二氧化硫	6.25×10^-2 kg/MWh
钢板	1.67×10^-5 kg/MWh	氮氧化物	4.19×10^-2 kg/MWh
铁	3.42×10^-5 kg/MWh	一氧化碳	1.78×10^-2 kg/MWh
电力	4.21×10^-4 MJ/MWh
