CIESC Journal ›› 2024, Vol. 75 ›› Issue (10): 3477-3487.DOI: 10.11949/0438-1157.20240470
• Fluid dynamics and transport phenomena • Previous Articles Next Articles
Received:
2024-04-28
Revised:
2024-06-22
Online:
2024-11-04
Published:
2024-10-25
Contact:
Yuan YU
通讯作者:
于源
作者简介:
刘克润(1998—),男,硕士研究生,2021200640@buct.edu.cn
基金资助:
CLC Number:
Kerun LIU, Yuan YU. Study of aggregate fragmentation laws in turbo air classification flow field[J]. CIESC Journal, 2024, 75(10): 3477-3487.
刘克润, 于源. 涡流空气分级流场中团聚体破碎规律研究[J]. 化工学报, 2024, 75(10): 3477-3487.
参数 | 数值 |
---|---|
空气动力黏度μ/(Pa·s) | 1.83×10-5 |
空气密度 | 1.205 |
颗粒密度 | 2700 |
杨氏模量E/GPa | 2 |
泊松比 | 0.2 |
时间步长δt/s | 10-8 |
Hamaker常数A/J | 5×10-19[ |
颗粒表面能 | 0.0826[ |
进口风速/(m·s-1) | 12 |
转笼转速/(r·min-1) | 1200 |
Table 1 Parameter settings in the numerical simulation
参数 | 数值 |
---|---|
空气动力黏度μ/(Pa·s) | 1.83×10-5 |
空气密度 | 1.205 |
颗粒密度 | 2700 |
杨氏模量E/GPa | 2 |
泊松比 | 0.2 |
时间步长δt/s | 10-8 |
Hamaker常数A/J | 5×10-19[ |
颗粒表面能 | 0.0826[ |
进口风速/(m·s-1) | 12 |
转笼转速/(r·min-1) | 1200 |
