三丁基（丙基）季离子液体对VOCs的吸收性能及机理

doi:10.11949/0438-1157.20240296

摘要/Abstract

摘要：

为拓展和探究离子液体在挥发性有机物（VOCs）吸收领域的潜在应用和机理，以乙醚、丙酮和二氯甲烷为VOCs代表，模拟计算了三种季类离子液体（PILs），即三丁基（丙基）季四氟硼酸盐（[P₄₄₄₃][BF₄]）、三丁基（丙基）季双三氟甲基磺酰亚胺盐（[P₄₄₄₃][Tf₂N]）、三丁基（丙基）季三氟乙酸盐（[P₄₄₄₃][CF₃COO]）吸收单分子和多分子VOCs的活性位点、氢键、吸收能（E_abs）、电荷等。研究表明，PILs与三种VOCs之间均形成了氢键并伴随电荷转移，阴离子对乙醚和丙酮吸收的影响不显著；阴离子对二氯甲烷的吸收则起主要作用，[CF₃COO]^-的E_abs值明显较大。[P₄₄₄₃]⁺类离子对一般具有3个类似的吸收活性位点，其容纳VOCs分子的空间主要由阳离子提供。离子液体的双离子对空间结构分析表明，由碱性弱且体积较大阴离子组成的PILs更容易暴露其吸收位点。实验研究进一步表明，相比咪唑类离子液体，PILs表现出优异的VOCs吸收能力。

关键词: 离子液体, 模拟, 挥发性有机物, 吸收, 密度泛函理论

Abstract:

In order to expand and explore the potential applications and mechanism analysis of ionic liquids in the field of volatile organic compounds (VOCs) absorption, diethyl ether, acetone and dichloromethane were used as representatives of VOCs, through the quantum chemistry calculation module DMol3 in Materials Studio software, at the DNP/GGA/PW91 level. VOCs absorption sites of single-molecule and multi-molecules, hydrogen bonds, absorption energies (E_abs) and charge of three quaternary phosphine ionic liquids (PILs) were simulated and calculated, which are tributyl(propyl)phosphonium tetrafluoroborate ([P₄₄₄₃][BF₄]), tributyl(propyl)phosphonium bis(trifluoromethyl-sulfonyl)imide ([P₄₄₄₃][Tf₂N]), and tributyl(propyl)phosphonium tetrafluoroacetate ([P₄₄₄₃][CF₃COO]). Accompanied by charge transfer, hydrogen bonds are formed between PILs and three types of VOCs. The dominant role of PILs in absorbing different types of VOCs is different. In the process of absorbing VOCs, anions and cations have different effects on the absorption. The results showed that the anions of PILs have little effect on the absorption of ether and acetone. The hydrogen bonds formed by the anions of PILs and α-H of ether are weak. The absorption sites of PILs for acetone are mainly the cation α-H or β-H and carbonyl O, and anions play a major role in the absorption of methylene chloride. The main role of PILs and methylene chloride is the hydrogen bond formed by the basic active site of the anion and the H of methylene chloride. The E_abs of [CF₃COO]^- for methylene chloride are obviously prominent. [P₄₄₄₃]⁺ ion pairs generally have three similar absorption active sites, and the space for accommodating VOCs molecules is mainly provided by cations. Analysis of the double ion pair spatial structure of ionic liquids shows that PILs composed of weakly basic and larger anions are more likely to expose their absorption sites. Experimental studies further show that compared with imidazole ionic liquids, PILs exhibit excellent VOCs absorption capabilities.

Key words: ionic liquids, simulation, volatile organic compounds, absorption, density functional theory

中图分类号:

TQ 09

赵非凡, 朱佳媚, 康洁, 檀亮, 段靖瑜. 三丁基（丙基）季离子液体对VOCs的吸收性能及机理[J]. 化工学报, 2024, 75(10): 3669-3680.

Feifan ZHAO, Jiamei ZHU, Jie KANG, Liang TAN, Jingyu DUAN. Absorption characteristics and mechanism of VOCs by tributyl(propyl)phosphonium ionic liquid[J]. CIESC Journal, 2024, 75(10): 3669-3680.

图/表 14

参考文献 42

1	张智, 马修卫, 李津津, 等. 中高温环境下VOCs在活性炭上的吸附性能研究[J]. 化工学报, 2019, 70(12): 4811-4820.
	Zhang Z, Ma X W, Li J J, et al. Study on adsorption capacity of VOCs on activated carbon at medium-high temperature[J]. CIESC Journal, 2019, 70(12): 4811-4820.
2	孟博文, 李永波, 孟晶, 等. 我国经济快速发展区工业VOCs排放特征及管控对策[J]. 环境科学, 2021, 42(3): 1023-1038.
	Meng B W, Li Y B, Meng J, et al. Industrial emission characteristics and control countermeasures of VOCs in Chinese rapid economic development areas[J]. Environmental Science, 2021, 42(3): 1023-1038.
3	He L, Duan Y S, Zhang Y, et al. Effects of VOC emissions from chemical industrial parks on regional O 3 - PM_2.5 compound pollution in the Yangtze River Delta[J]. Science of the Total Environment, 2024, 906: 167503.
4	Biard P F, Couvert A, Giraudet S. Volatile organic compounds absorption in packed column: theoretical assessment of water, DEHA and PDMS50 as absorbents[J]. Journal of Industrial and Engineering Chemistry, 2018, 59: 70-78.
5	Davarpanah M, Hashisho Z, Crompton D, et al. Modeling VOC adsorption in lab- and industrial-scale fluidized bed adsorbers: effect of operating parameters and heel build-up[J]. Journal of Hazardous Materials, 2020, 400: 123129.
6	Wu Z Q, Cao X W, Li M, et al. Treatment of volatile organic compounds and other waste gases using membrane biofilm reactors: a review on recent advancements and challenges[J]. Chemosphere, 2024, 349: 140843.
7	Campesi M A, Luzi C D, Barreto G F, et al. Evaluation of an adsorption system to concentrate VOC in air streams prior to catalytic incineration[J]. Journal of Environmental Management, 2015, 154: 216-224.
8	Lou B Z, Shakoor N, Adeel M, et al. Catalytic oxidation of volatile organic compounds by non-noble metal catalyst: current advancement and future prospectives[J]. Journal of Cleaner Production, 2022, 363: 132523.
9	Makoś-Chełstowska P. VOCs absorption from gas streams using deep eutectic solvents—a review[J]. Journal of Hazardous Materials, 2023, 448: 130957.
10	武宁, 杨忠凯, 李玉, 等. 挥发性有机物治理技术研究进展[J]. 现代化工, 2020, 40(2): 17-22.
	Wu N, Yang Z K, Li Y, et al. Research progress in VOCs treatment technology[J]. Modern Chemical Industry, 2020, 40(2): 17-22.
11	Wang L Y, Zhang Y J, Liu Y, et al. SO₂ absorption in pure ionic liquids: solubility and functionalization[J]. Journal of Hazardous Materials, 2020, 392: 122504.
12	Mu M L, Zhang X F, Yu G Q, et al. Deep removal of chlorobenzene based volatile organic compounds from exhaust gas with ionic liquids[J]. Separation and Purification Technology, 2022, 298: 121610.
13	Fahri F, Bacha K, Chiki F F, et al. Air pollution: new bio-based ionic liquids absorb both hydrophobic and hydrophilic volatile organic compounds with high efficiency[J]. Environmental Chemistry Letters, 2020, 18(4): 1403-1411.
14	Sharma P, Sharma S, Kumar H. Introduction to ionic liquids, applications and micellization behaviour in presence of different additives[J]. Journal of Molecular Liquids, 2024, 393: 123447.
15	Goutham R, Rohit P, Vigneshwar S S, et al. Ionic liquids in wastewater treatment: a review on pollutant removal and degradation, recovery of ionic liquids, economics and future perspectives[J]. Journal of Molecular Liquids, 2022, 349: 118150.
16	Zhang W L, Luo J P, Sun T F, et al. The absorption performance of ionic liquids—PEG200 complex absorbent for VOCs[J]. Energies, 2021, 14(12): 3592.
17	Xu R N, Dai C N, Mu M L, et al. Highly efficient capture of odorous sulfur-based VOCs by ionic liquids[J]. Journal of Hazardous Materials, 2021, 402: 123507.
18	Yu G Q, Dai C N, Gao H, et al. Capturing condensable gases with ionic liquids[J]. Industrial & Engineering Chemistry Research, 2018, 57(36): 12202-12214.
19	Zhao X, Xing H B, Yang Q W, et al. Differential solubility of ethylene and acetylene in room-temperature ionic liquids: a theoretical study[J]. The Journal of Physical Chemistry B, 2012, 116(13): 3944-3953.
20	Zheng Y Z, Chen H, Zhou Y, et al. Microscopic properties of two 1-(2′-hydroxylethyl)-3-methylimidazolium-based ionic liquids and methanol mixtures[J]. Journal of Molecular Liquids, 2020, 313: 113578.
21	Gui C M, Li G X, Zhu R S, et al. Capturing VOCs in the pharmaceutical industry with ionic liquids[J]. Chemical Engineering Science, 2022, 252: 117504.
22	Song M H, Gui C M, Lei Z G. Experimental and simulation studies on the capture of chlorinated volatile organic compounds by ionic liquids[J]. Industrial & Engineering Chemistry Research, 2023, 62(26): 10184-10194.
23	Mu M L, Yu G Q, Zhang X F, et al. Deep removal of dichloromethane using ionic liquids: thermodynamic and molecular insights[J]. Chemical Engineering Science, 2024, 284: 119498.
24	Wang X, Zhang M J, Li L C, et al. Supported fluorine-free ionic liquids with highly sensitive gas-sensing performance[J]. Journal of Molecular Liquids, 2023, 390: 123122.
25	Kianpour E, Azizian S, Yarie M, et al. A task-specific phosphonium ionic liquid as an efficient extractant for green desulfurization of liquid fuel: an experimental and computational study[J]. Chemical Engineering Journal, 2016, 295: 500-508.
26	Macarie L, Simulescu V, Ilia G. Phosphonium-based ionic liquids used as reagents or catalysts[J]. ChemistrySelect, 2019, 4(32): 9285-9299.
27	Cao Y Y, Mu T C. Comprehensive investigation on the thermal stability of 66 ionic liquids by thermogravimetric analysis[J]. Industrial & Engineering Chemistry Research, 2014, 53(20): 8651-8664.
28	Freire M G, Neves C M S S, Marrucho I M, et al. Hydrolysis of tetrafluoroborate and hexafluorophosphate counter ions in imidazolium-based ionic liquids[J]. The Journal of Physical Chemistry A, 2010, 114(11): 3744-3749.
29	Solomon K R, Velders G J M, Wilson S R, et al. Sources, fates, toxicity, and risks of trifluoroacetic acid and its salts: relevance to substances regulated under the Montreal and Kyoto Protocols[J]. Journal of Toxicology and Environmental Health Part B, Critical Reviews, 2016, 19(7): 289-304.
30	Arjomand Kermani N, Petrushina I, Rokni M M. Evaluation of ionic liquids as replacements for the solid piston in conventional hydrogen reciprocating compressors: a review[J]. International Journal of Hydrogen Energy, 2020, 45(33): 16337-16354.
31	Tan L, Zhu J M, He X D, et al. The mechanism of toluene absorption by phosphonium ionic liquids with multiple sites[J]. Journal of Molecular Liquids, 2021, 331: 115501.
32	魏显珍, 赵玉海, 赵斌, 等. 典型印刷工业VOCs排放特征及其污染防治效果分析[J]. 能源环境保护, 2022, 36(4): 91-98.
	Wei X Z, Zhao Y H, Zhao B, et al. Emission characteristics of VOCs from the typical printing industry and control performance by pollution prevention facilities[J]. Energy Environmental Protection, 2022, 36(4): 91-98.
33	党在清. 涂料生产企业挥发性有机物治理工艺技术及效果分析[J]. 中国石油和化工标准与质量, 2023, 43(24): 190-192.
	Dang Z Q. Treatment technology and effect analysis of volatile organic compounds in coating production enterprises[J]. China Petroleum and Chemical Standard and Quality, 2023, 43(24): 190-192.
34	汪前胜. 医药化工行业VOC废气治理存在的问题及改进措施[J]. 化工管理, 2022(8): 35-37.
	Wang Q S. Problems and improvement measures of VOC waste gas treatment in pharmaceutical and chemical industry[J]. Chemical Management, 2022(8): 35-37.
35	王瑞文, 张春林, 丁航, 等. 电子制造业塑料件生产过程的挥发性有机物排放特征分析[J]. 环境科学学报, 2019, 39(1): 4-12.
	Wang R W, Zhang C L, Ding H, et al. Emission characteristics of volatile organic compounds (VOCs) from the production processes of plastic parts in electronic manufacturing industry[J]. Acta Scientiae Circumstantiae, 2019, 39(1): 4-12.
36	Cui Y H, Chen Y F, Deng D S, et al. Difference for the absorption of SO₂ and CO₂ on [P _nnnm ][Tetz] (n=1, m=2, and 4) ionic liquids: a density functional theory investigation[J]. Journal of Molecular Liquids, 2014, 199: 7-14.
37	Gao T T, Andino J M, Alvarez-Idaboy J R. Computational and experimental study of the interactions between ionic liquids and volatile organic compounds[J]. Physical Chemistry Chemical Physics: PCCP, 2010, 12(33): 9830-9838.
38	Kang J, Lu S J, Zhu J M, et al. Absorption performance and mechanism of volatile organic compounds by phosphonium ionic liquids with different anions[J]. Journal of Chemical Technology & Biotechnology, 2024, 99(7): 1541-1552.
39	Dong K, Zhang S J, Wang J J. Understanding the hydrogen bonds in ionic liquids and their roles in properties and reactions[J]. Chemical Communications, 2016, 52(41): 6744-6764.
40	Zhang X C, Jiang K, Liu Z P, et al. Insight into the performance of acid gas in ionic liquids by molecular simulation[J]. Industrial & Engineering Chemistry Research, 2019, 58(3): 1443-1453.
41	Wu W L, Li T, Gao H S, et al. Efficient absorption of dichloromethane using imidazolium based ionic liquids[J]. The Chinese Journal of Process Engineering, 2019, 19(1): 173-180.
42	Gui C M, Li G X, Lei Z G, et al. Experiment and molecular mechanism of two chlorinated volatile organic compounds in ionic liquids[J]. Industrial & Engineering Chemistry Research, 2023, 62(2): 1160-1171.

构型	Mulliken电荷/e
构型	[P₄₄₄₃]⁺	[BF₄]^-	[Tf₂N]^-	[CF₃COO]^-	1-乙醚	2-乙醚	3-乙醚
[P₄₄₄₃][BF₄]	0.898	-0.9	—	—	—	—	—
[P₄₄₄₃][BF₄]∙DEE	0.89	-0.902	—	—	0.009	—	—
[P₄₄₄₃][BF₄]∙2DEE	0.887	-0.893	—	—	0.010	-0.007	—
[P₄₄₄₃][BF₄]∙3DEE	0.882	-0.891	—	—	0.008	-0.004	0.005
[P₄₄₄₃][Tf₂N]	0.928	—	-0.930	—	—	—	—
[P₄₄₄₃][Tf₂N]∙DEE	0.913	—	-0.924	—	0.013	—	—
[P₄₄₄₃][Tf₂N]∙2DEE	0.912	—	-0.931	—	0.009	0.009	—
[P₄₄₄₃][Tf₂N]∙3DEE	0.901	—	-0.930	—	0.009	0.010	0.009
[P₄₄₄₃][CF₃COO]	0.832	—	—	-0.831	—	—	—
[P₄₄₄₃][CF₃COO]∙DEE	0.826	—	—	-0.833	0.007	—	—
[P₄₄₄₃][CF₃COO]∙2DEE	0.828	—	—	-0.833	0.002	0.006	—
[P₄₄₄₃][CF₃COO]∙3DEE	0.842	—	—	-0.834	0.002	0.003	-0.011

构型	Mulliken电荷/e
构型	[P₄₄₄₃]⁺	[BF₄]^-	[Tf₂N]^-	[CF₃COO]^-	1-乙醚	2-乙醚	3-乙醚
[P₄₄₄₃][BF₄]	0.898	-0.9	—	—	—	—	—
[P₄₄₄₃][BF₄]∙DEE	0.89	-0.902	—	—	0.009	—	—
[P₄₄₄₃][BF₄]∙2DEE	0.887	-0.893	—	—	0.010	-0.007	—
[P₄₄₄₃][BF₄]∙3DEE	0.882	-0.891	—	—	0.008	-0.004	0.005
[P₄₄₄₃][Tf₂N]	0.928	—	-0.930	—	—	—	—
[P₄₄₄₃][Tf₂N]∙DEE	0.913	—	-0.924	—	0.013	—	—
[P₄₄₄₃][Tf₂N]∙2DEE	0.912	—	-0.931	—	0.009	0.009	—
[P₄₄₄₃][Tf₂N]∙3DEE	0.901	—	-0.930	—	0.009	0.010	0.009
[P₄₄₄₃][CF₃COO]	0.832	—	—	-0.831	—	—	—
[P₄₄₄₃][CF₃COO]∙DEE	0.826	—	—	-0.833	0.007	—	—
[P₄₄₄₃][CF₃COO]∙2DEE	0.828	—	—	-0.833	0.002	0.006	—
[P₄₄₄₃][CF₃COO]∙3DEE	0.842	—	—	-0.834	0.002	0.003	-0.011

构型	Mulliken电荷/e
构型	[P₄₄₄₃]⁺	[BF₄]^-	[Tf₂N]^-	[CF₃COO]^-	1-丙酮	2-丙酮	3-丙酮
[P₄₄₄₃][BF₄]∙DMK	0.890	-0.897	—	—	0.006	—	—
[P₄₄₄₃][BF₄]∙2DMK	0.888	-0.896	—	—	0.005	0.006	—
[P₄₄₄₃][BF₄]∙3DMK	0.887	-0.879	—	—	-0.002	-0.001	-0.003
[P₄₄₄₃][Tf₂N]∙DMK	0.913		-0.926		0.011	—	—
[P₄₄₄₃][Tf₂N]∙2DMK	0.917	—	-0.928	—	0.005	0.009	—
[P₄₄₄₃][Tf₂N]∙3DMK	0.912	—	-0.928	—	0.009	0.009	-0.001
[P₄₄₄₃][CF₃COO]∙DMK	0.849	—	—	-0.845	-0.007	—	—
[P₄₄₄₃][CF₃COO]∙2DMK	0.864	—	—	-0.848	-0.006	-0.010	—
[P₄₄₄₃][CF₃COO]∙3DMK	0.866	—	—	-0.847	-0.006	-0.007	-0.006

构型	Mulliken电荷/e
构型	[P₄₄₄₃]⁺	[BF₄]^-	[Tf₂N]^-	[CF₃COO]^-	1-丙酮	2-丙酮	3-丙酮
[P₄₄₄₃][BF₄]∙DMK	0.890	-0.897	—	—	0.006	—	—
[P₄₄₄₃][BF₄]∙2DMK	0.888	-0.896	—	—	0.005	0.006	—
[P₄₄₄₃][BF₄]∙3DMK	0.887	-0.879	—	—	-0.002	-0.001	-0.003
[P₄₄₄₃][Tf₂N]∙DMK	0.913		-0.926		0.011	—	—
[P₄₄₄₃][Tf₂N]∙2DMK	0.917	—	-0.928	—	0.005	0.009	—
[P₄₄₄₃][Tf₂N]∙3DMK	0.912	—	-0.928	—	0.009	0.009	-0.001
[P₄₄₄₃][CF₃COO]∙DMK	0.849	—	—	-0.845	-0.007	—	—
[P₄₄₄₃][CF₃COO]∙2DMK	0.864	—	—	-0.848	-0.006	-0.010	—
[P₄₄₄₃][CF₃COO]∙3DMK	0.866	—	—	-0.847	-0.006	-0.007	-0.006

构型	Mulliken电荷/e
构型	[P₄₄₄₃]⁺	[BF₄]^-	[Tf₂N]^-	[CF₃COO]^-	1-二氯甲烷	2-二氯甲烷	3-二氯甲烷
[P₄₄₄₃][BF₄]∙DCM	0.895	-0.891	—	—	-0.003	—	—
[P₄₄₄₃][BF₄]∙2DCM	0.902	-0.889	—	—	-0.003	-0.008	—
[P₄₄₄₃][BF₄]∙3DCM	0.893	-0.885	—	—	0.000	-0.006	-0.001
[P₄₄₄₃][Tf₂N]∙DCM	0.908	—	-0.915	—	0.006	—	—
[P₄₄₄₃][Tf₂N]∙2DCM	0.910	—	-0.908	—	0.000	-0.003	—
[P₄₄₄₃][Tf₂N]∙3DCM	0.901	—	-0.905	—	0.002	-0.005	-0.001
[P₄₄₄₃][CF₃COO]∙DCM	0.837	—	—	-0.827	-0.014	—	—
[P₄₄₄₃][CF₃COO]∙2DCM	0.840	—	—	-0.823	-0.012	-0.008	—
[P₄₄₄₃][CF₃COO]∙3DCM	0.847	—	—	-0.828	-0.006	-0.009	-0.005
